Wide Screen 21inch 1080P Waterproof Panel Pc, Touchscreen Android Tablet
Features
1. 21.5inch lcd panel with 1920*1080 full resolution
2. Rockchip RK3399 Processor low power consumption
3. IP Grade: Full IP65 /67/69
4. I/O: 2*USB, 1*RJ45, 1*DC jack, 1*RS232
5. WIFI with waterproof Antenna
6. PoE
Configuration
| Processor System | CPU | RK3399 | |
| Memory | 2GB/4GB | ||
| Storage | 16G EMMC(8G/16G/32G optional) | ||
| Operation System | Android 6.0/7.0/8.0 | ||
| LCD Panel Characteristics | Screen Size | 21.5-inch Lcd Panel | |
| Touchscreen Type | Capacitive touch screen | ||
| Resolution | 1920(H)x 1080(V) | ||
| Aspect Ratio | 16:9 | ||
| Brightness | 250nits | ||
| Contrast Ratio | 500:1 | ||
| Response Time | 10 msec | ||
| I/O Interface | PoE | it support 802.3af and 802.3at.(Optional) | |
| USB | 2xUSB2.0 | ||
| LAN | RJ45 as PoE power supply | ||
| COM | RS232 | ||
| Function | Full IP65 | ||
| WIFI | |||
| Optional | AG glass | ||
| UV Protect | |||
| sunlight readable | |||
| waterproof | |||
| Brightness control button | |||
| Power Supply | Single 12 V DC power input, Max 18W Power Consumption | ||
| Accessories | 8A Power Adapter with cable | ||
| Working Temperature | -20~70° C | ||
| Other Information | Material | metal | |
| Color | Black/Silver/White | ||
| Mounting | Wall mount/ Panel mount | ||
Applications
Industrial plant
Oil, Gas and Chemicals Industrial
Animal Feed Production Facility
CNC Control Panel
Rugged Environment Application
Food & Beverage Processing Instrument
Customization
size-7-42inch optional
Touch-capacitive/ Resistive/IR touch
AG / AR glass
Optically bound
1000cd/m2 sunlight readable brightness
Factory Advantages
1. Rich experience--INNODA have 10years rich experience in Industrial Computer/monitor filed. Our eingineers all have at least 13years experience.
2. Widely usage--7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer,
sunlight readable pc/monitor, android tablet...etc. which have excellent work performane.It offers rich of interface to meet csutomers needs.
3. ODM / OEM ability---INNODA own designers and engineers, our team have a lot of successful case experience
like The Opera House, Panasonic, Scales system...etc
