Windows10 Embedded Touch Panel Pc Outdoor Computer Full IP65 32G SSD

Basic Information
Place of Origin: Shenzhen,China
Brand Name: INNODA
Certification: CE,RoHS, FCC
Model Number: IND173PC
Minimum Order Quantity: 1piece
Price: Negotiable
Packaging Details: 1pc/carton weight: 7kgs/pc, packing size: 48×14×39cm
Delivery Time: 12working days upon receive the payment
Payment Terms: T/T, Western Union, L/C, Paypal/D/P, D/A, MoneyGram
Supply Ability: 5000 pieces per month
Detail Information
Type: Full Ip65 Capacitive Touch Panel Pc Size: 17.3inch Lcd Panel With 1920*1080
Waterproof IP Grade: IP65 / IP66 / IP67 Optional WIFI: Wifi With Waterproof Antenna Optional
High Light:

Windows10 Touch Panel Pc 36V


IP65 Touch Panel Pc


32G Touch Panel Pc

Product Description

Windows10 Outdoor Computer Embedded Full IP65 Capacitive Touch Panel Pc
Features of full ip65 capacitive touch panel pc
1. IP65 waterproof, also can choose IP66/ IP67 /IP69K

2. Intel celeron J4105 processor, J1900 / i3/ i5/ i7 as choice

3. Aluminum enclosure with fanless design, which is good for heat dissipation


Configuration of full ip65 capacitive touch panel pc

Processor System CPU Intel Quad Core J4105/1.5 GHz I/O Port COM 1 x RS232(Up to 4COM)
Memory 2GB (up to 8G) USB 2 x USB2.0(up to 4USB)
Storage 32G SSD(up to 1TB) LAN 1/2 x RJ45, 10/100/1000 Mbps
Operation System WIndows 7/8/10 OS(trial version) Function IP65 waterproof
LCD Panel Characteristics Screen Size 17.3’ LED Panel,16:9 (7-22'' option) Waterproof WIFI antenna(optional)
Touchscreen Type Capacitive touch screen/Resistive  Optional 8-36V wide voltage
Resolution 1920(H)x 1080(V) PoE
Brightness 300cd/m2 WIFI / Bluetooth is built-in
Other Information Power supply 110V-220V, 12V DC Input Camera / RFID / NFC / Scanner built-in
Working Temperature 0-50℃ Enclosure Metal/Aluminum/Stainless Steel (optional)
Mounting 75*75/100*100mm VESA Cooling system Fanless

Accessories of full ip65 capacitive touch panel pc
USB, COM, Lan and power cables are waterproof IP68 grade, which is good to prevent water

power adapter also are waterproof

Windows10 Embedded Touch Panel Pc Outdoor Computer Full IP65 32G SSD 0


Customization service of full ip65 capacitive touch panel pc

1000nits brightness for sunlight readable

Anti-glare glass

9-36V wide voltage

GPS, 4G modem


Application of full ip65 capacitive touch panel pc

Industrial filed---factory automation system contol

Consumer field---kiosk, advertisement machine, ticket device

Smart home---telecom system, kitchen
