2xlan Industrial Panel Pc Rugged PCAP touchscreen

Basic Information
Place of Origin: Shenzhen,China
Brand Name: INNODA
Certification: CE,RoHS, FCC
Model Number: IND080PC
Minimum Order Quantity: 1piece
Price: Negotiable
Packaging Details: 1pc/carton weight: 4.5kgs/pc, packing size: 31×31×11cm
Delivery Time: 12working days upon receive the payment
Payment Terms: T/T, Western Union, L/C, Paypal/D/P, D/A, MoneyGram
Supply Ability: 5000 pieces per month
Detail Information
Type: 8-inch Rugged Panel Pc Resolution: 1024*768
Touchscreen: PCAP Touchscreen CPU: Intel Quad-core J1900
Wide Voltage: 24V Voltage Cooling: Fanless
Warranty: 12 Months Material: Aluminum+Metal
High Light:

2xlan Industrial Panel Pc Rugged

,

PCAP Touchscreen Industrial Panel Pc Rugged


Product Description

2xRj45 Industrial Rugged Panel Pc 8-Inch Lcd Panel With 24v Wide Voltage
Features
1. 8inch durable rugged panel pc

2. True color lcd panel with 1024*768 resolution

3. Quad-core Intel J1900/2.0Ghz

4. 10points sensistive capacitive touchscreen

5. 24V wide voltage built-in

6. I/O: 2*Lan,



Configuration

Processor System CPU Intel Quad-core J1900/2.0GHz
Memory 4GB-8GB
Storage 64G SSD(up to 1TB)
Operation System Windows 7/8/10 OS(trial version)
LCD Panel Characteristics Screen Size 8’’ Lcd Panel
Touchscreen Type Capacitive touch screen / Resistive touch option
Resolution 1024(H)x768(V)
Aspect Ratio 4:3
Brightness 250cd/m2
Contrast Ratio 500:1
Response Time 10 msec
I/O Interface COM 1*RS232(RS485/RS422 optional)
USB 4xUSB2.0
LAN 2xRJ45, 10/100/1000 Mbps
HDMI yes
VGA 1xVGA
Function 24V wide voltage
Brightness automatic sensor
WIFI
Optional RFID/ NFC card reader
8-36V wide range voltage
Brightness control button
1000nits High Brightness for sunlight readable
Front waterproof / Full sealed Waterproof
Power Supply Single 12 V DC power input, Max 18W Power Consumption
Accessories 8A Power Adapter with cable
Working Temperature -20~70° C
Other Information Material Metal frame
Color Black/Silver/White
Mounting VESA mount / Embedded
Certificates CE/ RoHS / FCC


Detailed Image
2xlan Industrial Panel Pc Rugged PCAP touchscreen 02xlan Industrial Panel Pc Rugged PCAP touchscreen 1



Customization service
1) CPU Intel Celeron 1037, J1900, Core i3 i5 i7 optional
2) 10.4" 15" 17" 19" LCD panel
3) IR touch, Resistive touch optional
4) Memory 2G 4G 8G
5) Hard disk 32G 64G 128GB, 256GB SSD, HDD 500GB,1TB

2xlan Industrial Panel Pc Rugged PCAP touchscreen 2

Our Advantage
1. Experience

INNODA have 10years rich experience in Industrial Computer/monitor filed. Our eingineers all have at least

13years experience.
2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer,

sunlight readable pc/monitor, android tablet...etc. which have excellent work performane.
3. Customization functions
It offers rich of interface to meet csutomers needs.
4.Widely useage environment
INNODA computer/monitor which is widly used for kitchen,food industry, boat...etc

5. No MOQ limited

We can provide sample first to test it for the big project.

2xlan Industrial Panel Pc Rugged PCAP touchscreen 3


 Any interested, welcome to ask for more information
